Wet  Heating Corporation


· It is suitable for new construction

· There is no risk of freezing in winter because hot water pipes are not used

· After construction, cement is completed, so the floor is hard

·The cement is heated to keep warm for a long time



Order of construction

1. Install insulation (4.5mm)

2. Arrange carbon fiber heating elements

3. Attach the aluminum heat diffusion sheet

4. install a glass fiber mesh

5. thermostat installation

6. Fever test

7. cement-pouring construction

Installation sectional view


Height of floor raised by 41.3 to 46.3 mm after installation

Spec

Name
Function
insulation Width 1 m × 50 m Thickness: 4.5 mm
▶ Insulation that prevents heat from going down to the floor to prevent heat loss and moisture.
Carbon fiber heating element

Effective carbon fiber : 24K (24000 strands)
coating : Heat-resistant silicone
Electric capacity : 32w/1m, 556.8w(17.4m)/1 flat

new material carbon fiber
▶ My fever: I don't ride in high temperature.
▶ durability: 1/5 light and more than 10 or more.
▶ flexibility: flexibility.
Aluminum Thermal
Diffusion Sheet
0.6 m (width) × 50 m (cell) Thickness: 0.3 mm
▶Excellent thermal conductivity using high-purity aluminum.
▶ It can maximize cooling and heating efficiency.
fiber protection plate
Width 1 m × 50 m Thickness: 1 mm
▶ Cement crack prevention
thermostat

4kw capacity thermostat

▶It is a front-fastening 4 kW thermostat.

▶You can adjust the temperature from 1 to 10 stages

▶It has a timer function

▶It can be used in various ways for electric heating products.

▶ Minimize power waste and prepare for safety accidents by preventing long-term use of high temperatures.

▶Apply PC ABS flame to prevent safety accidents due to heat resistance
